System Settings
ZFX-C User’s Manual
5
ADDITIONAL FUNCTIONS
141
Output Conditions
When "Serial output" or "SD card" is output as the data output destination, set the output form and output
format.
ASCII format
When outputting measurement values in ASCII format, set the following items.
X MENU mode - [System] - [Output] - [Date format (Serial)/(SD Card)]
Output format
Setup Item Description
Output form Selects ASCII.
Digits of integer Sets the number of output digits of the integer section. When "0" is selected, all of the dig-
its of the data are output shifted to the left.
When there are fewer data digits than the preset number of digits, "0" is inserted in free
digits.
When there are more data digits than the preset number of digits, "9" is output for the pre-
set number of digits.
Range: 0 to 8 (default value: 8)
Digits of decimal Sets the number of output digits past the decimal point. When "0" is selected, digits past
the decimal point are rounded up to the nearest integer.
Range: 0 to 3 (default value: 3)
Field separator Sets the separator between individual output data items.
Range: None, Comma (default value), Tab, Space, Semicolon
Decimal separator Sets the number of digits past the decimal point.
Range: None, Period (default value), Comma
Record separator Sets the separator between individual output data records.
Range: None, Comma, Tab, Space, Delimiter (default value)
Display at time Prefixes the output data with time information.
Range: OFF (default value), ON
File name Sets the name of the output file. (only when SD card is selected) The directory "OUTFILE"
is automatically created in the root directory of the SD card. Output files are stored in this
directory.
When Display at time is set to "ON", the data is prefixed with the time information.
To Next Page
