Specifications and External Dimensions
ZFX-C User’s Manual
7
APPENDICES
185
Camera only
ZFX-S/SC
*1: 3Z4S-LT are not yet released for overseas.
Item ZFX-S (monochrome type) ZFX-SC (color type)
Image capture element All-pixel capture inter-line transfer type
1/3" CCD (monochrome)
All-pixel capture inter-line transfer type
1/3" CCD (color)
Effective number of pixels 659 (H) x 494 (V)
Pixel size 7.4 µm (H) x 7.4 µm (V)
Shutter speed 1/170 to 1/20000 s
Partial function (partial capture) Not available 1/2 partial, 1/4 partial
Image rate function Fine, Normal, High speed Not available
Frame rate
(at capture of entire screen)
90 fps
Lens mount C mount
Lighting Optional lighting
I/F
Available
External lighting: 3Z4S-LT *1
Flash Controller: made by Moritex Corporation 3Z4S-LT MLEK-C100E1TSX *1
Ratings Power supply
voltage (supplied
from Controller)
15 VDC, 48 VDC
Current consumption
Approx. 160 mA
Operation
environment
robustness
Ambient
temperature range
Operating: 0 to + 50°C, Storage: -25 to +65°C (with no icing or condensation)
Ambient humidity
range
Operating and storage: 35% to 85% (with no condensation)
Ambient atmo-
sphere
No corrosive gases allowed
Degree of protection
IP20 (IEC60529)
Dielectric strength 500 VAC 50 Hz/60 Hz 1 min
Vibration resis-
tance (durability)
10 to 150 Hz Single-amplitude 0.35 mm Acceleration: 50 m/s
2
10 times for 8 min each in X, Y, and
Z directions
Shock resistance
(destructive)
150 m/s
2
3 times each in 6 directions (up/down, left/right, forward/backward)
Connection method Connector connection type (camera cable ZFX-VS/VSR required)
Material Case: Aluminum die cast alloy (C mount section), zinc die cast alloy (mounting base side), Cover:
Zinc-plated copper plate 0.5 mm thick, Camera mounting base: ABS
Weight Approx. 80 g
Accessories Instruction Sheet
