Omron ZFX-C User Manual

Specifications and External Dimensions
194
ZFX-C User’s Manual
Right Angle Camera Cable
ZFX-VSLA 3M/8M, ZFX-VSRLA 3M
ZFX-VSLB 3M/8M, ZFX-VSRLB 3M
Item ZFX-VSLA 3M ZFX-VSLA 8M ZFX-VSRLA 3M ZFX-VSLB 3M ZFX-VSLB 8M ZFX-VSRLB 3M
Applicable Controller ZFX
Cable type Standard cable Robot cable Standard cable Robot cable
Cable length 3 m 8 m 3 m 3 m 8 m 3 m
Minimum bending radius 40 mm
Weight Approx. 250 g Approx. 550 g Approx. 250 g Approx. 250 g Approx. 550 g Approx. 250 g
19.1 5.9
29
L
25.34
38.14
26-pole (male)26-pole (male)
Vinyl insulated round cable
6.1 mm dia. 15-core
Nameplate
5.9 8
22
24.8
15.6
26.2
24.2
40
L: ZFX-VSLA/VSRLA 3M : 3 m
ZFX-VSLA 8M : 8 m
(Unit: mm)
24.8
15.6
26-pole (male)
19.1
40
24.2
26.2
5.9
29 L
25.34
38.14
85.9
22
Nameplate
26-pole (male)
L: ZFX-VSLB/VSRLB 3M : 3 m
ZFX-VSLB 8M : 8 m
Vinyl insulated round cable
6.1 mm dia. 15-core
(Unit: mm)
