Specifications and External Dimensions
ZFX-C User’s Manual
7
APPENDICES
205
*1: Applicable standards IEC60825-1:1993 +A1:1997 +A2:2001, EN60825-1:1994 +A2:2001 +A1:2002
Item ZFV-LTF01 ZFV-LTL01 ZFV-LTL02 ZFV-LTL04
Applicable camera ZFV, ZFX
Lighting method Pulse lighting
Lighting interval Fixed (1.1 to 1.4 ms)
Lighting source White LEDs x 60 p'ces White LEDs x 20 p'ces White LEDs x 40 p'ces White LEDs x 80 p'ces
Power supply voltage 48 VDC (supplied from camera)
Current consumption Approx. 160 mA Approx. 80 mA Approx. 120 mA Approx. 210 mA
Dielectric strength 300 VAC 50 Hz/60 Hz 1 min
Vibration resistance (durability)
10 to 150 Hz Single-amplitude 0.35 mm 10 times for 8 min each in X, Y, and Z directions
Shock resistance (destructive)
150 m/s
2
3 times each in 6 directions (up/down, left/right, forward/backward)
Ambient temperature range Operating: 0 to + 40°C, Storage: -20 to +65°C (with no icing or condensation)
Ambient humidity range Operating and storage: 35% to 85% (with no condensation)
Ambient atmosphere No corrosive gases allowed
Connection method Cable built-in type (standard cable length: 2 m)
Degree of protection IP20 (IEC60529)
Material SPCC SPCC, aluminum
Weight Approx. 500 g (packaged
state: approx. 550 g)
Approx. 250 g (packaged
state: approx. 300 g)
Approx. 650 g (packaged
state: approx. 900 g)
Approx. 900 g (packaged
state: approx. 1,150 g)
LED Class
*1
Class 1
