Setting Measurement Items
62
ZFX-C User’s Manual
• Verification and Candidate level p.49
• Search Rotation Range p.49
• Setting the Candidate level p.49
• Coordinates mode p.75
When the sensitivity, rotation range, and skipping angle have been changed, register the model again.
Possible output results
The following values can be output when expressions are set.
The minimum size of subdivided models is 32 x 32 pixels.
Item Description Message
Judgment result The judgment result is output. (0:OK, -1:NG, -2: not measured) Judge (JG)
Correlation The degree of match between the measurement image and model
image are output as a correlation value. The correlation and position
information of the model having the lowest degree of match of the
subdivided models is output. (0 to 100)
Correlation (CR)
Measurement position When [Difference position] is selected at [Output position]:
The X, Y coordinates of the location having the lowest correlation
value, as a result of having calculated the correlation value in detail by
subdivided models, are output. (-9999.999 to 9999.999)
When [Center position] is selected at [Output position]:
The center coordinates of the model that was found are output.
(-9999.999 to 9999.999)
Position X, Y
(X, Y)
Solid color rate The rate that the model is a solid color is output. The higher the solid
color rate, the higher the value increases. (0 to 100)
Solid color rate
(SC)
Measurement angle The rotation angle of the model that was found is output. (-180 to 180) Angle (TH)
