Setting Measurement Items
68
ZFX-C User’s Manual
Threshold
This function sets the judgment conditions.
Judgment is performed on corresponding label Nos.
X MENU mode - [Setup] - [Item] - [Limits]
Detailed settings (if necessary)
When measurement is not stable, adjust the detailed conditions.
X MENU mode - [Setup] - [Item] - [Detail]
Setup Item Description
Area Sets the range of the area to be judged as OK.
Range: 0 to 9999999.999 (When calibration is OFF, the range of the area becomes 0 to
307200.)
Gravity XY Sets the range of movement in the X- and Y-axes of the measurement target to be judged
as OK.
Range: -9999.999 to 9999.999 (When calibration is OFF, the range of movement for posi-
tions X and Y are 0 to 640 and 0 to 480, respectively.)
Number of labels Sets the number of labels of the measurement target to be judged as OK.
Range: 0 to 65535
Axis angle Sets the rotating range of the measurement target to be judged as OK.
Range: -90.0 to 90.0
+/- direction of angle
p.64
Perimeter Sets the perimeter of the measurement target to be judged as OK.
Range: 0 to 9999999.999 (When calibration is OFF, the range of the perimeter becomes 0
to 200000.)
Length XY Sets the X and Y lengths of the box circumscribing the measurement target to be judged
as OK.
Range: -9999.999 to 9999.999 (When calibration is OFF, the range of movement for posi-
tions X and Y are 0 to 640 and 0 to 480, respectively.)
Roundness Sets the roundness of the measurement target to be judged as OK.
Range: 0 to 1.0
Setup Item Setting value Description
Labeling mode Precision The image is measured without being compressed.
Normal (default value) The image is measured at high speed after being compressed
to 1/2 size in both the horizontal and vertical directions.
Sort mode Area descending order
(default value)
Re-assigns label Nos. in order of the largest area.
Area ascending order Re-assigns label Nos. in order of the smallest area.
X gravity descending order
Re-assigns label Nos. in order of the largest X gravity coordinate.
X gravity ascending order
Re-assigns label Nos. in order of the smallest X gravity coordinate.
Y gravity descending order
Re-assigns label Nos. in order of the largest Y gravity coordinate.
Y gravity descending order
Re-assigns label Nos. in order of the smallest Y gravity coordinate.
Label No. 0 to 2499 (default value: 0) Sets the label No. whose data is to be output.
Measure axis angle OFF (default value) When set to "ON", the axis angle is calculated.
ON
