Setting Measurement Items
70
ZFX-C User’s Manual
Possible output results
The following values can be output when expressions are set.
Reference position and position difference p.50
Item Description Message
Judgment result The judgment result is output. (0: OK, -1: NG, -2: not measured) Judge (JG)
Area The area of the corresponding label is output. (0 to 9999999.999) Area (AR)
Gravity position The X, Y coordinates of the gravity of the corresponding label are out-
put. (-9999.999 to 9999.999)
Gravity X, Y (X, Y)
Number of labels The total number of labels is output. (0 to 65535)
Number of labels (N)
Axis angle The angle of the corresponding label is output. (-90.0 to 90.0) Axis angle (TH)
Perimeter
The perimeter of the corresponding label is output. (0 to 9999999.999)
Perimeter (L)
Length XY The X and Y lengths of the box circumscribing the corresponding
label are output. (0 to 9999.999)
Length X, Y
(LX, LY)
Roundness The roundness of the corresponding label is output. (0 to 1.0) Roundness (CL)
Reference area The area of the corresponding label when the measurement region is
set is output. (0 to 9999999.999)
Ref. area (SA)
Reference position The X, Y coordinates of the gravity of the corresponding label when
the measurement region is set are output. (-9999.999 to 9999.999)
Reference X, Y
(SX, SY)
Reference axis angle The angle of the corresponding label when the measurement region
is set are output. (-90.0 to 90.0)
Ref. axis angle
(ST)
Reference perimeter The perimeter of the corresponding label when the measurement
region is set is output. (0 to 9999999.999)
Ref. perimeter
(SL)
Reference length XY The X and Y lengths of the box circumscribing the corresponding
label when the measurement region is set are output. (0 to 9999.999)
Ref. length X, Y
(SLX, SLY)
Reference roundness The roundness of the corresponding label when the measurement
region is set is output. (0 to 1.0)
Ref. roundness
(SC)
Area difference The area difference obtained by "measurement value - reference
value" is output. (-9999999.999 to 9999999.999)
Diff. area (DA)
Position difference The position difference obtained by "gravity position - reference posi-
tion" is output. (-9999.999 to 9999.999)
Displacement X, Y
(DX, DY)
Axis angle difference The axis angle difference obtained by "measurement value - refer-
ence value" is output. (-180.0 to 180.0)
Diff. axis angle
(DT)
Perimeter difference The perimeter difference obtained by "measurement value - reference
value" is output. (-9999999.999 to 9999999.999)
Diff. perimeter
(DL)
Length XY difference The length difference obtained by "measurement value - reference
value" is output. (-9999.999 to 9999.999)
Diff. length X, Y
(DLX, DLY)
Roundness difference The roundness difference obtained by "measurement value - refer-
ence value" is output. (-1.0 to 1.0)
Diff. roundness
(DC)
