Setting Measurement Items
72
ZFX-C User’s Manual
Threshold
This function sets the judgment conditions.
X MENU mode - [Setup] - [Item] - [Limits]
Image adjustment (if necessary)
The following items can be changed and set to the image of the measurement target.
X MENU mode - [Setup] - [Item] - [Img Adj]
Setup Item Description
Position XY Sets the range of movement in the X- and Y- axes of the measurement target to be judged
as OK.
Range: -9999.999 to 9999.999
(When calibration is OFF, the range of movement for positions X and Y are 0 to 640 and 0
to 480, respectively.)
Item Description
Select camera
For details, see "Image Adjustment". p.99
Selects which of Color filter or Color Pickup is to be used at [Detail] - [Color mode].
The default is use of Color filter.
Color filter
Color Pickup/Binary
Filtering
BGS level
