Setting Measurement Items
84
ZFX-C User’s Manual
Threshold
This function sets the judgment conditions.
X MENU mode - [Setup] - [Item] - [Limits]
Image adjustment (if necessary)
The following items can be changed and set to the image of the measurement target.
X MENU mode - [Setup] - [Item] - [Img Adj]
Setup Item Description
Angle Sets the angle range of the measurement target to be judged as OK.
Range: -180.00 to 180.00
The angle calculated by edge angle is calculated as follows according to the positional
relationship between the 2 edge positions.
Position 1XY Sets the range of movement in the X- and Y- axes of measurement region 1 of the mea-
surement target to be judged as OK.
Range: -9999.999 to 9999.999
(When calibration is OFF, the range of movement for positions X and Y are 0 to
640 and 0 to 480, respectively.)
Position 2XY Sets the range of movement in the X- and Y- axes of measurement region 2 of the mea-
surement target to be judged as OK.
Range: -9999.999 to 9999.999
(When calibration is OFF, the range of movement for positions X and Y are 0 to
640 and 0 to 480, respectively.)
Item Description
Select Camera
For details, see "Image Adjustment." p.99
Selects which of Color filter or Color Pickup is to be used at [Detail] - [Color mode]. The
default is use of Color filter.
Color filter
Color Pickup/Binary
Filtering
BGS level
: Edge position 1 : Edge position 2
-180 to 0°
0 to 180°
