Setting Measurement Items
86
ZFX-C User’s Manual
Possible output results
The following values can be output when expressions are set.
For details on reference position, position difference p.50
Item Description Message
Judgment result The judgment result is output. (0: OK, -1: NG, -2: not measured) Judge (JG)
Edge angle The measured angle is output. (-180 to 180) Angle (TH)
Edge position The X, Y coordinates of the edge position are output. (-9999.999 to
9999.999)
Position X, Y
(X, Y)
Reference angle The angle when the measurement region is set is output. (-180 to 180) Ref. angle (ST)
Reference position The X, Y coordinates of the edge position when the measurement
region is set are output. (-9999.999 to 9999.999)
Reference X, Y
(SX, SY)
Angle difference The difference obtained by "measurement angle - reference angle " is
output. (-360 to 360)
Angle dif. (DT)
Position difference The difference obtained by "measurement position - reference position"
is output. (-9999.999 to 9999.999)
Position dif. X, Y
(DX, DY)
