OPHIR BeamSquared - 1.3 Specifications

Specifications 1.3
Environmental
Storage Temperature
-30°C to 65°C
Storage Humidity
95% maximum (non-condensing)
Operating Temperature
10°C to 40°C
Operating Humidity
95% maximum (non-condensing)
Power Requirements*
Input Voltage
90 – 264 V AC
AC Line Current
1.6 A
Line Frequency
47Hz to 63Hz
Output Voltage
24V DC @ 5 A
Output Power
120 W
* For the optical train only. The PC computer supplies the power for the system components and the SP300
and SP920 CCD camera. The XC-130 camera has a separate power supply.
Physical
Weight
26 lbs. (without camera)
Standard Optics
Different lenses are required for different wavelength regions, spot sizes, and divergences. Five lenses are
included with the SP300 and SP920 systems, and two lenses with the XC-130 system. See below for nominal
focal lengths. Additional lenses must be ordered separately.
BSQ-SP300
BSQ-XC130
BSQ-SP920
BSQ-A
Included
Lenses
266-440nm UV
500mm FL
430-700nm VIS
500mm FL
430-700nm VIS
400mm FL
650-1000nm NIR
400mm FL
1000-1550nm NIR
extended 400mm FL*
650-1000nm NIR
400mm FL
1000-1700nm NIR
extended 400mm FL
266-440nm UV
500mm FL
430-700nm VIS
500mm FL
430-700nm VIS
400mm FL
650-1000nm NIR
400mm FL
1000-1550nm NIR
extended 400mm FL*
266-440nm UV
500mm FL
430-700nm VIS
500mm FL
430-700nm VIS
400mm FL
650-1000nm NIR
400mm FL
1000-1550nm NIR
extended 400mm FL*
* The SP300 and SP920 cameras are only sensitive between 190-1100nm.
