C200 SOFTWARE
Instruction Manual C200 Part2 A1.doc
optek Danulat GmbH • D-45356 Essen • Germany
page 63
Temperature Coefficient
Enter the temperature coefficient (α x 100) of the solution (0.01 to 5.0%/°C). If
unknown, the temperature coefficient (α) of the solution must be calculated – see
section 7.2.2.
If the value has not yet been calculated, set it to 2%/°C provisionally.
Filter Time
Set the required filter time, between 1 and 60 seconds in 1 second increments.
Sensor B configuration (dual input analyzers only) is identical to
Sensor A configuration.
See Section 5.2.4.
Edit User Defined Temperature Compensation
Select Yes to manually define a 6-point temperature compensation curve,
otherwise select No.
Continued on next page.
Filter Time
Set the required filter time, between 1 and 60 seconds in 1 second increments.
Sensor B configuration (dual input analyzers only) is identical to
Sensor A configuration.
See section 5.2.4.
A: Temp.Coeff.
2.00
%/°C
A: Temp.Comp.
set to
Linear
A: Filter Time
10
Secs
Config. Sensor A
CONFIG. ALARMS
Config. Sensor B
User Temp Comp
Edit
-----
A: Temp.Comp.
set to
User
Yes
No
A: Enter Point 1
A: Filter Time
10
Secs
Config. Sensor A
CONFIG. ALARMS
Config. Sensor B
Yes
No
