Oracle ZFS Storage Appliance Service Manual

ZS3-4 Controller Hardware Overview
Slot
Mfg Part
Number
Description Max Note
5 7070195 4-port 1GbE UTP Ethernet 4 Optional recommended front-
end
5 7051223 2-port 10Gb Ethernet Optical
NIC
6 Optional recommended front-
end
5 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or initiator
(backup)
5 7023303 2-port 16Gb FC HBA 4 Optional FC target or initiator
(backup)
6 7070006 2-port 10Gb Ethernet Copper
NIC
4 Optional recommended front-
end
6 375-3696-01 2-port InfiniBand CX2 HCA 4 Optional recommended front-
end
6 7070195 4-port 1Gb Ethernet Copper
UTP NIC
4 Optional recommended front-
end
6 7051223 2-port 10Gb Ethernet Optical
NIC
6 Optional recommended front-
end
6 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or initiator
(backup)
6 7023303 2-port 16Gb FC HBA 4 Optional FC target or initiator
(backup)
7 7067091 4-port (4x4) external HBA 4 Additional optional back-end
7 7070006 2-port 10Gb Ethernet Copper
NIC
4 Optional recommended front-
end
7 371-4325-02 2-port 8Gb FC HBA 4 Optional recommended front-
end
7 375-3696-01 2-port InfiniBand CX2 HCA 4 Optional recommended front-
end
7 7051223 2-port 10Gb Ethernet Optical
NIC
6 Optional recommended front-
end
7 7070195 4-port 1Gb Ethernet Copper
UTP NIC
4 Optional recommended front-
end
7 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or initiator
(backup)
7 7023303 2-port 16Gb FC HBA 4 Optional FC target or initiator
(backup)
8 7067091 4-port (4x4) SAS-2 external
HBA
4 Base configuration
9 371-4325-02 2-port 8Gb FC HBA 4 Optional FC target or initiator
(backup)
9 7070006 2-port 10Gb Ethernet Copper
NIC
4 Optional recommended front-
end
Servicing the ZS3-4 Controller 123

Oracle ZFS Storage Appliance Specifications

General

Connectivity	10GbE, 40GbE, InfiniBand, Fibre Channel
Protocols	NFS, SMB, iSCSI, Fibre Channel, HTTP
Operating System	Oracle Solaris
Data Protection	snapshots, clones, remote replication
Data Reduction	Inline compression, deduplication
High Availability	Redundant hardware components (controllers, power supplies, fans). Automatic failover between controllers. Hot-swappable drives and components. Cluster configurations for increased availability and scalability.
Management Interface	Web-based GUI, CLI, REST API
Storage Type	Hybrid (SSD + HDD), All-Flash
Storage Capacity	Up to several petabytes
Encryption	AES-256 encryption at rest
