Oracle ZFS Storage Appliance Service Manual

ZS3-4 Controller Hardware Overview
Slot
Mfg Part
Number
Description Max Note
9 7070195 4-port 1Gb Ethernet Copper
UTP NIC
4 Optional recommended front-
end
9 7051223 2-port 10Gb Ethernet Optical
NIC
6 Optional recommended front-
end
9 7023303 2-port 16Gb FC HBA 4 Optional FC target or initiator
(backup)
ZS3-4 NIC/HBA Options - This table describes NIC/HBA PCIe card options for ZS3-4
standalone and cluster configurations.
TABLE 20
ZS3-4 Controller NIC/HBA Options
Mktg Part Number Description
SG-SAS6-INT-Z 8-port 6Gb/s SAS-2 internal HBA
SG-XPCIE2FC-QF8-Z 2-port 8Gb FC HBA
7103791 4-port (4x4) SAS-2 6Gb/s external HBA
7101674 2-port 16Gb FC HBA
7100477 4-port 1Gb Ethernet Copper UTP
7100488 2-port 10Gb Ethernet Copper Base-T
X4242A 2-port InfiniBand CX2 HCA
X1109A-Z 2-port 10GbE SFP+ NIC
X2129A Transceiver 850NM, 1/10GPS, Short Reach, SFP
X5562A-Z Transceiver 10GbE/1GbE, Long Reach, SFP
ZS3-4 PCIe Slot Order - When installing additional PCIe cards to your base configuration,
cards must be added in a specific order.
Note - Slot 0 is always populated with a SAS-2 internal HBA. Slots 1 and 8 are reserved for
4x4 SAS-2 external HBAs.
124 Oracle ZFS Storage Appliance Customer Service Manual • July 2016

Oracle ZFS Storage Appliance Specifications

General

Connectivity	10GbE, 40GbE, InfiniBand, Fibre Channel
Protocols	NFS, SMB, iSCSI, Fibre Channel, HTTP
Operating System	Oracle Solaris
Data Protection	snapshots, clones, remote replication
Data Reduction	Inline compression, deduplication
High Availability	Redundant hardware components (controllers, power supplies, fans). Automatic failover between controllers. Hot-swappable drives and components. Cluster configurations for increased availability and scalability.
Management Interface	Web-based GUI, CLI, REST API
Storage Type	Hybrid (SSD + HDD), All-Flash
Storage Capacity	Up to several petabytes
Encryption	AES-256 encryption at rest
