Oracle ZFS Storage Appliance Service Manual

7420 Controller Hardware Overview
Slot Mfg Part Number Description Max Note
6 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
6 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
6 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
7 F375-3609-03
(7059331 for EU
countries)
DP SAS external
HBA
6 Additional optional
back-end
7 7054739 4-port copper NIC 6 Optional
recommended front-
end
7 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
7 375-3606-03 CX1 InfiniBand
HCA
4 Optional
recommended front-
end
7 7051223 2-port optical 10GE
NIC
6 Optional
recommended front-
end
7 375-3696-01 CX2 InfiniBand
HCA
4 Optional
recommended front-
end
8 F375-3609-03
(7059331 for EU
countries)
2-port SAS external
HBA
6 Base configuration
(2 minimum)
9 371-4325-02 8Gb 2-port FC HBA 6 Optional FC target or
initiator (Backup)
9 7051223 2-port optical 10GbE
NIC
6 Optional
recommended front-
end
9 7054739 4-port copper NIC 6 Optional
recommended front-
end
7420 NIC/HBA Options - This table describes NIC/HBA PCIe card options for standalone and
cluster configurations.
TABLE 32
7420 Controller NIC/HBA Options
Mktg Part Number Description Mfg Part Number
SGX-SAS6-INT-Z 8-port 6Gb/s SAS-2 internal HBA 7054001
Servicing the 7x20 Controller 227

Oracle ZFS Storage Appliance Specifications

General

Connectivity	10GbE, 40GbE, InfiniBand, Fibre Channel
Protocols	NFS, SMB, iSCSI, Fibre Channel, HTTP
Operating System	Oracle Solaris
Data Protection	snapshots, clones, remote replication
Data Reduction	Inline compression, deduplication
High Availability	Redundant hardware components (controllers, power supplies, fans). Automatic failover between controllers. Hot-swappable drives and components. Cluster configurations for increased availability and scalability.
Management Interface	Web-based GUI, CLI, REST API
Storage Type	Hybrid (SSD + HDD), All-Flash
Storage Capacity	Up to several petabytes
Encryption	AES-256 encryption at rest
