ZS4-4 Controller Hardware Overview
FIGURE 5
ZS4-4 Network Management Port
Serial Management Port
The serial management connector (SER MGT), shown in the figure below, is an RJ-45 port and
provides a terminal connection to the SP console.
FIGURE 6
ZS4-4 Serial Management Port
4x4 SAS-2 HBA
The 4x4 SAS-2 HBA provides connectivity to external DE2-24 disk shelves. The HBA ports
are numbered 3-0, top to bottom, as shown in the following figure.
78 Oracle ZFS Storage Appliance Customer Service Manual • July 2016
