Oracle ZFS Storage Appliance Service Manual

ZS4-4 Controller Hardware Overview
Slot Description Max Type Note
9 16GB Dual Universal FC HBA 4 B Optional FC target or initiator
(Backup)
10 2-port InfiniBand CX3 HCA 4 A Optional recommended front-
end
10 2-port 10Gb Ethernet Optical
NIC
4 C Optional recommended front-
end
10 2-port 10Gb Ethernet Copper
NIC
4 D Optional recommended front-
end
10 16GB Dual Universal FC HBA 4 B Optional FC target or initiator
(Backup)
11 2-port InfiniBand CX3 HCA 4 A Optional recommended front-
end
11 2-port 10Gb Ethernet Optical
NIC
4 C Optional recommended front-
end
11 2-port 10Gb Ethernet Copper
NIC
4 D Optional recommended front-
end
11 16GB Dual Universal FC HBA 4 B Optional FC target or initiator
(Backup)
The legend describes the interconnect types and option codes shown in the Type column.
Legend for Interconnect Types and Options
A InfiniBand QDR QSFP+
- QSFP Direct Copper Cable
Connect
- Optical Transceiver QSFP Short
Range 40Gbs
E Storage Array 4-port External SAS-2
Mini-SAS HD
- SFF-8644 Mini-SAS HD to Mini-
SAS Copper
B Fibre Channel 16Gb SFP+
- Optical Transceiver SFP Short
Range 16Gbs
F HDD 8-port Internal SAS-2 Mini-
SAS
-SFF-8087 Mini-SAS to Mini-SAS
Copper
C GbE NIC Multi-mode Fiber SFP+
10GBase-SR/LR
- Optical Transceiver SFP Short
Range 10Gbs
- Optical Transceiver SFP Long
Range 10Gbs
G Server Heartbeat 2-port RS-232 1-
port 1GBase-T
-Copper RJ-45 Serial RS-232
-Copper RJ-45 Unshielded Twisted
Pair
D GbE NIC UTP 10GBase-T
82 Oracle ZFS Storage Appliance Customer Service Manual • July 2016

Oracle ZFS Storage Appliance Specifications

General

Connectivity	10GbE, 40GbE, InfiniBand, Fibre Channel
Protocols	NFS, SMB, iSCSI, Fibre Channel, HTTP
Operating System	Oracle Solaris
Data Protection	snapshots, clones, remote replication
Data Reduction	Inline compression, deduplication
High Availability	Redundant hardware components (controllers, power supplies, fans). Automatic failover between controllers. Hot-swappable drives and components. Cluster configurations for increased availability and scalability.
Management Interface	Web-based GUI, CLI, REST API
Storage Type	Hybrid (SSD + HDD), All-Flash
Storage Capacity	Up to several petabytes
Encryption	AES-256 encryption at rest
