ZS4-4 Controller Hardware Overview
Slot Description Max Type Note
1 16GB Dual Universal FC HBA 4 B Optional FC target or initiator
(Backup)
2 8-port SAS-2 Internal HBA 1 F Base configuration
3 4-port (4x4) SAS-2 External
HBA
4 E Optional back-end
3 2-port InfiniBand CX3 HCA 4 A Optional recommended front-
end
3 2-port 10Gb Ethernet Optical
NIC
4 C Optional recommended front-
end
3 2-port 10Gb Ethernet Copper
NIC
4 D Optional recommended front-
end
3 16GB Dual Universal FC HBA 4 B Optional FC target or initiator
(Backup)
4 Cluster Interface (second
generation)
1 G Base configuration
5 2-port InfiniBand CX3 HCA 4 A Optional recommended front-
end
5 2-port 10Gb Ethernet Optical
NIC
4 C Optional recommended front-
end
5 2-port 10Gb Ethernet Copper
NIC
4 D Optional recommended front-
end
5 16GB Dual Universal FC HBA 4 B Optional FC target or initiator
(Backup)
6 4-port (4x4) SAS-2 External
HBA
4 E Base configuration
7 4-port (4x4) SAS-2 External
HBA
4 E Base configuration
8 2-port InfiniBand CX3 HCA 4 A Optional recommended front-
end
8 2-port 10Gb Ethernet Optical
NIC
4 C Optional recommended front-
end
8 2-port 10Gb Ethernet Copper
NIC
4 D Optional recommended front-
end
8 16GB Dual Universal FC HBA 4 B Optional FC target or initiator
(Backup)
9 4-port (4x4) SAS-2 External
HBA
4 E Base configuration
9 2-port InfiniBand CX3 HCA 4 A Optional recommended front-
end
9 2-port 10Gb Ethernet Optical
NIC
4 C Optional recommended front-
end
9 2-port 10Gb Ethernet Copper
NIC
4 D Optional recommended front-
end
