Operating Instructions Intelligent Controller
160
Conguring the system
Setting
Set the distribution mode Set the mode used for distributing when calculating charges. There are two methods for distribution. Time distribution: This method calculates distribution ratios based on the operating times of the indoor
units (thermostat ON cumulative time and thermostat OFF cumulative time).
Load distribution: This method calculates distribution ratios based on the electricity/gas usage (including
standby power) of the indoor units and outdoor units.
Item Explanation
Distribution modes
Set the distribution mode (time distribution or load distribution).
GasDist/PwGn Select whether to calculate distributions when
using gas for power generation.
y When set to “No”, you cannot set charge each
area and billing method.
Charge each area
Select whether to use charge each area for gas power generation.
y When set to “No”, you cannot set billing
method.
Billing method Set the billing method for gas power generation. Energy savng dist
Set the range of energy savings effects for multi- function air conditioners or ice thermal storage models in calculations for distribution. (when load distribution only)
y With “O/D system”, only the air conditioning
distribution of the area of the outdoor system is reected.
y With “DistrGrp”, the air conditioning
distribution of all areas in the entire distribution group is reected.
PwrDistr calc trgt Set the target of electricity distribution
calculation.
y “OpertnTime” is distributed between the
electricity for both outdoor units and indoor units.
y “T/S ONTime” is distributed to the electricity
for only outdoor units.
4
Touch [Register].
z To cancel the settings, touch [Cancel].
4
1
Touch [System Settings] in “Settings”.
z The “System settings” screen is displayed.
1
2
Touch [Distribution mode settings].
z The “Distribution mode settings” screen is displayed.
2
3
Change the settings.
161
Conguring the system
Setting
Set the units for electricity/gas charges Set the units for electricity and gas charges.
3
Change the settings.
z The touchscreen numeric keypad appears when you touch
the text box.
Item Explanation
ElecPrceRate GasPriceRate
The screen switches to the one for setting the prices for electricity or gas charges. The highlighted item after touching is the one that will be set.
TmeSltUPrc Set the regular hour range 1 to 8 price.
y The time slot for the regular hour range is the
one set in “Regular hour range settings” in “Calendr sttgs for distr calc” (P.150).
OutOfHrs Set the out of hours price. SpcfdDay Set the specied days price.
y The specied day is the one set in
“SpeciedDayCalendar” in “Calendr sttgs for distr calc” (P.149).
AllHours Set prices for times that are not covered by
regular hour ranges, out of hours, or specied days.
CCY code Enter the currency unit.
4
Touch [Register].
z To cancel the settings, touch [Cancel].
4
1
Touch [System Settings] in “Settings”.
z The “System settings” screen is displayed.
1
2
Touch [Distribution Ratio settings].
z The “Distribution Ratio settings” screen is displayed.
2
