Conguring the system
Setting
The “Event control” screen A: Set the event name with . You can
change the event names. (→ “Changing an event name” (P.167))
B: The settings for the selected event name
are enabled if you put a check mark here.
C: Select the conditions.
AND The event at the output point is
executed when the conditions set for the input point are all met.
OR
The event at the output point is executed when at least one of the conditions set for the input point are met.
D: Set the output point event execution timing
(time). The “OutptDlayTme” setting dialogue is displayed when you touch this. Setting values are “0Sec.”, “1Sec.”, “3Sec.”, “5Sec.”, “10Sec.”, “30Sec.”, “1Min.”, “3Min.”, “5Min.”, and “10Min.”.
E: The list of input points that are set is
displayed.
Input point This displays the input targets for which conditions are set. Type The input target type is displayed. Status The input target status is displayed. Symbol A symbol is displayed when temperature is set as a condition for indoor units. The symbols displayed are as follows:
↑: When the temperature is set to “min.” ↓: When the temperature is set to “max.”
F: The list of output points that are set is displayed.
Output point This displays the output targets for which conditions are set. Type The output target type is displayed. Output The output target status is displayed.
G: When an input point border or output point border is selected and you touch it, the dialogue for setting each of them is displayed.
A B C D
E F
G
Linked control of air conditioning units
167
Conguring the system
Setting
Changing an event name
1
Touch the text box.
z The touchscreen keyboard is displayed.
1
2
Enter the text.
Setting the operation mode
1
Touch [Swtch] in the “Output point settings” dialogue.
z The “OpertnMode” dialogue is displayed.
1
2
Select the mode to switch.
z The settings are registered and the “OpertnMode” dialogue
closes.
2
Deleting the settings for input/output points
1
Select the input/output point to delete (1-
1) and touch [Set] (1-2).
z The settings dialogue is displayed.
1-
1
1-
2
2
Touch the highlighted input/output target.
z The setting is deleted.
2
3
Touch [Register].
z The setting dialogue closes, and the selected input/output
point is deleted from the list.
3
Linked control of air conditioning units
