Conguring the system
Setting
Registering a communication adaptor Register communication adaptors connected to this unit to enable communications with the air conditioning units. 1
Touch [System Settings] in “Settings”.
1
2
Touch [Communication adapter setting].
z The “Communication adapter setting” screen is displayed.
2
3
Put a check mark in the “Select” column.
z Select the communication adaptor to be edited.
3
4
Touch [Sttng].
z The “Edit CommAdptrStgs” dialogue is displayed.
4
5
Change the settings.
Item Explanation
Name Change the name of the communication adaptor.
You can enter up to 16 letters or numbers.
6
Touch [Register].
z The “Edit CommAdptrStgs” dialogue closes. z To cancel the settings, touch [Cancel].
6
Continued on next page
171
Conguring the system
Setting
7
Repeat steps 3 to 6 to edit other communication adaptors.
8
Put a check mark in the “Register” column.
z Put a check mark next to the communication adaptors you
want to enable.
8
9
Touch [Register].
z To cancel the settings, touch [Cancel].
9
The “Communication adapter setting” screen A: A list of communication adaptors with a check
mark in the “Register” column is displayed when you touch this. Touch again to return to the previous display.
B: Put a check mark next to the communication
adaptor you want to edit.
C: Put a check mark next to the communication
adaptors you want to enable.
D: The “Edit CommAdptrStgs” dialogue is displayed
when you touch this.
Note
y In the “Address” column, “Link1” and “Link2” are
in this unit, and addresses such as “1-Link1” and “1-Link2” are the addresses of added communication adaptors.
