28
Check the status of air conditioning units
Operation/Status
Checking the operational status of indoor units
Check the operational status of indoor units (remaining lter time, number of operation cycles, etc.) in a
list.
You can also change the ventilation system and demand control settings (ON or OFF only).
1
Touch [Operation/Status] in “Oper./
Status”.
1
2
Touch [I/D unit information].
z The “I/D unit information” screen is displayed.
2
3
Check the setting details. (P.29)
Note
y You can select indoor units to change their ventilation output
settings. (→ “Changing the settings for ventilation output” (P.30))
y You can select indoor units to change their demand control
settings. (→ “Changing the demand control settings” (P.31))
29
Check the status of air conditioning units
Operation/Status
“I/D unit information” screen
A: [Select all]/[Clear all] buttons
[Select all] Select all indoor units.
[Clear all] Cancel selection of all indoor
units.
B: Change list order. The list order changes each
time you touch it.
Address The display follows the address
order set in “I/D unit settings”
(P.141).
Display The display follows the order set
in “I/D unit settings” (P.141).
O/D unit The display follows the address
order of the outdoor unit systems.
C: Indoor unit details are displayed in a list.
You can scroll up or down by swiping or icking
the screen.
Item Explanation
[Select] Select the units you want to make ventilation settings or demand settings for.
Name The names of the indoor units are displayed.
You can change the names. (→ “I/D unit settings” (P.141))
Filter time
This displays the approximate time remaining before
is displayed.
OprCount The number of operation cycles for the day is displayed.
Demand Demand control setting status is displayed. “ON” is displayed when demand control is set. (→ “Demand settings on
the indoor unit” (P.89))
T/S This displays the operational status of the thermostat. “ON” is displayed when the thermostat is working.
Fan The fan strength (High/Mid./Low/Brze/OFF) is displayed.
SuctnTmp The current inlet temperature is displayed.
DschgTmp The current outlet temperature is displayed.
VentOpen The ventilation output setting (ON or OFF) is displayed.
D: Change the settings for ventilation output.
The “Vent.” dialogue is displayed when you touch this. (→ “Changing the settings for ventilation output” (P.30))
ON Operation of the ventilation output starts.
OFF Operation of the ventilation output stops.
E: Change the demand control settings.
The “Demand setting” dialogue is displayed when you touch this. (→ “Changing the demand control settings” (P.31))
ON Demand control is set.
Cancel Demand control is cancelled.
F: The contents currently displayed are output to the USB memory device as a CSV le.
A
B
C
DF E
Checking the operational status of indoor units
