Panasonic FP Web-Server2 - Modbus-TCP Server of the FP Web-Server in General

Modbus functions
158 FP Web-Server V2.810 EN
Function
Comment
A
Modbus-TCP server
(see p. 158)
A1 Modbus-TCP
server
Modbus-TCP client  FP Web-Server 
PLC (see note 2)
A2 Modbus-TCP
server
Modbus-TCP client  FP Web-Server 
multiple PLCs (see note 1 and note 2)
A3 Modbus-TCP
server gateway
Modbus-TCP client  FP Web-Server 
Modbus RTU slave (see note 1)
B
Modbus-TCP client
(see p. 160)
B1 Modbus-TCP
client
PLC  FP Web-Server  Modbus-TCP
server
B3 Modbus-TCP
client gateway
Modbus RTU master (see note 1)  FP
Web-Server  Modbus-TCP server
B5 Modbus-TCP
client for data_logger
FP Web-Server internal control from
Data logger (see p. 61) and FPWEB
Script (see p. 73)
In addition: Modbus
RTU functions (for
PLCs that do not
support Modbus RTU
protocol)
B2 Modbus RTU
master
PLC  FP Web-Server  Modbus RTU
slave (see note 1)
B4 Modbus RTU
slave
Modbus RTU master (see note 1)  FP
Web-Server  PLC
For an overview on all functions, please refer to the block diagram (see p.
14).
 This function uses the 2nd RS232C (9-pin Sub-D connector).
 Since Modbus protocol, in contrast to the PLC, only recognizes 4
different memory areas, a configurable address translation table
was implemented. This allows you to configure offsets so that
Modbus "coils" and "registers" correspond to the PLC's memory
areas: X, Y, R, DT, FL, WR, etc.
 Various functions can be combined and used simultaneously.
 Most functions support the same list of Modbus function codes.
 You can configure all these functions manually or with the help of
the wizard.
17.2 Modbus-TCP server of the FP Web-Server in general
The FP Web-Server can be accessed by a Modbus-TCP client (SCADA) via
Ethernet for PLC data communication. To do so, the FP Web-Server
requests PLC data (MEWTOCOL protocol) via the 3-pin or/and 9-pin
RS232C port or the serial ports (RS485, USB) of the FP Web expansion
Note
