Hardware description
28 FP Web-Server V2.810 EN
2.2 FP Web expansion unit
2.2.1 Introduction
Please read the safety instructions in important notes (see p. 21) and also
the section on mechanical installation (see p. 23) carefully.
The FP Web expansion unit allows you to extend the interfacing possibilities
of the Panasonic FP Web-Server unit.
The following main features are supported:
 USB/ Ethernet interface (remote programming monitoring and
visualization)
 RS485/ Ethernet interface (remote programming monitoring and
visualization)
 High-speed digital output
 SD card slot
See the technical data sheet (see p. 29) for supported standards and
protocols.
2.2.2 FP Web expansion unit package
The package for the FP Web expansion unit contains:
 FP Web Expansion unit
 Leaflet providing installation instructions
 Phoenix 3-pin screw terminal
 Phoenix 2-pin screw terminal
Comments:
 The FP Web expansion unit only works when connected to an FP-WEB2
unit.
 The FP-WEB2 unit is configured via the Control FP Web Configurator
Tool.
 The Control FP Web Configurator Tool can be purchased separately.
Note
