Panasonic FP Web-Server2 - Technical Data

Hardware description
FP Web-Server V2.810 EN 19
 LEDs (see p. 177).
 The expansion connector is for the FP Web expansion unit only.
 FP0 expansion units are not supported and may damage the FP-WEB2
unit.
 Only FP-WEB2 units with hardware version greater than 1.1 are
equipped with the connector for the FP Web expansion unit.
2.1.5 Technical data
Feature
Description: Type 1
Type 2
Product number
FP Web-Server
PN Hardware: FP-WEB
PN Hardware: FP-WEB2
PN Configurator: FPWEBTOOL2
PLC connection
PLC COM: RS232C via 3-pin screw terminal port Plug:
Phoenix product: MC1,5/3-ST-3,5 Order Number: 18 40
37 9
Modem / 2nd
RS232C
Modem COM: RS232C via 9-pin SUB-D port, with RTS,
CTS Plug: 9-pin SUB-D female
Power supply
24V DC Molex 35 plug on the bottom side of the unit
Ethernet connection
Ethernet-COM: 10BASE-T
via RJ45 female connector
10BASE-T / 100BASE-TX
autoneg via RJ45 female
connector
LEDs (see p. 177)
Power, Ethernet, PLC data
exchange
Power, Ethernet, Ethernet
data, PLC data
Protocols and
standards
TCP/IP, UDP/IP, DHCP, FTP, TELNET, http, https, SMTP,
ESMTP-Auth, POP3, PPP, IEC60870, NTP, Modbus,
DynDNS, SNMPv1
Flash memory
512KBytes
8MBytes
For further information, refer to Available Memory
Calculation in the online help.
RAM
512KBytes
8MBytes
Operating voltage
24V DC (10.8 – 26.4V DC supplied by class 2 circuit
only)
Current consumption
Approx. 75mA at 24V DC
Approx. 65mA at 24V DC
Degree of protection
IP20
Ambient temperature
0°C to +55°C
Storage temperature
-20°C to +70°C
Humidity
Max. 30% to 85% (non-condensing)
Vibration resistance
10Hz to 55Hz, 1 cycle per minute with a double
amplitude of 0.75mm; 10 minutes every X-, Y-, and
Z-axis
Shock resistance
Min. 10g; 4 times every X-, Y-, and Z-axis
Dimensions
Height 90mm, Width 25mm, Depth 64mm
Note
