Panasonic Lumix S1H User Manual

5. Focus/Zoom
126
0 On the recording screen, you can rotate the focus ring to display the MF Assist
screen. If the focus ring has been rotated to enlarge the display, the assist
screen will be exited a short time after you cease the operation.
0 You can also display the MF Assist screen by pressing the [ ].
0 During MF, pressing [AF ON] will activate AF.
0 The recording distance
reference mark is a mark used
to measure the recording
distance.
Use this when taking pictures
with MF or taking close-up
pictures.
0 You can change the Focus Peaking sensitivity and the display method:
[] ¨ [ ] ¨ [Focus Peaking] (l 402)
0 You can memorise the MF Assist position separately for vertical and horizontal
orientations:
[] ¨ [ ] ¨ [Focus Switching for Vert / Hor] (l 122)
0 You can change the display method of the magnified screen:
[] ¨ [ ] ¨ [MF Assist] (l 422)
0 You can change the MF Guide display units:
[] ¨ [ ] ¨ [MF Guide] (l 422)
0 You can disable focus ring operation:
[] ¨ [ ] ¨ [Focus Ring Lock] (l 422)
0 You can set the movement of the MF Assist position to loop:
[] ¨ [ ] ¨ [Looped Focus Frame] (l 425)
0 The camera memorises the focus point when you turn it off:
[] ¨ [ ] ¨ [Lens Focus Resume] (l 443)
0 The amount of focus movement can be set:
[] ¨ [ ] ¨ [Focus Ring Control] (l 443)

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
