Panasonic Lumix S1H User Manual

3. Basic Operations
71

Playback Screen
¢1 Pressing 34 switches the display information. (l 552)
– Detailed information display
– Histogram display
– Photo Style display
– White balance display
– Lens information display
¢2 This is a screen without blinking highlights display that is shown when [Blinking
Highlights] of the [Custom] ([Monitor / Display (Photo)]) is set to [ON].
In other than this screen, overexposed parts of the screen will blink. (l 436)
0 Press [ ] to switch between display/hide of the level gauge.
This can also be set by using [Level Gauge]. (l 438)
0 Control panel operation (l 75)
0 You can hide the control panel and black screen:
[] ¨ [ ] ¨ [Show/Hide Monitor Layout] (l 439)
0 The display can be changed so that live view and display information do not
overlap:
[] ¨ [ ] ¨ [LVF/Monitor Disp. Set] (l 435)
With information
Detailed
information
display
¢1
Without
information
Display without
blinking
highlights
¢2
2019.12.1 10:00 100-0001 1/999
ISO 100 F 4.060
±
0
L
FINE
100
100-0001
ISO
0
F4.0 60
2019.12. 1 10:00
s
RGB
1/5
FINE
AFS
STD.
L
3:2
AWB

Panasonic Lumix S1H Specifications

General

Sensor Type	Full-frame CMOS
Resolution	24.2MP
ISO Range	100-51200 (expandable to 50-204800)
Viewfinder	5.76 million-dot OLED
Sensor Size	35.6 x 23.8 mm
Lens Mount	L-Mount
Video Recording	6K/24p, 5.9K/30p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
LCD Screen	3.2-inch, 2.33 million-dot touchscreen
Autofocus System	Contrast-detect DFD AF, 225-area
Connectivity	Wi-Fi, Bluetooth
Battery Life	Approx. 400 shots (CIPA standard)
Continuous Shooting	9 fps
Internal Recording	10-bit 4:2:2
Shutter Speed	1/8000 to 60 sec
Video Frame Rates	24p, 30p, 60p
Storage Media	Dual SD card slots (UHS-II compatible)
Weather Sealing	Yes
