10. The Final Transmission Assembly
10-5
114
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 10: THE FINAL TRANSMISSION ASSEMBLY
Replacing the Bearing (on the
side of the crankcase)
1. Remove the driving shaft (the
clutch main shaft).
Then remove the oil seal of the
shaft.
2. Use a bearing puller to remove
the bearing in the final transmission
gearbox.
3. Drive the new bearing into the
final transmission gearbox. Install
the new oil seal fro the drive shaft.
Assembling the Final Gear Set
1. First, install the drive shaft into
the final gearbox. Then install the
final transmission gear shaft
(output shaft) to the final gearbox.
1a
2
1b
DRIVING SHAFT
O-RING
BEARING
To Next Page
