NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 9: DRIVING BELT DEVICE & THE STARTING LEVER
Topic Page
Important Points 9-2
Troubleshooting 9-2
Detaching the Left Crankcase Cover 9-3
Removing the Starting Pivot 9-3
Checking the Starting Pivot 9-4
Installing the Starting Assembly 9-4
Assembling the Left Crankcase Cover 9-5
Checking the Driving Belt 9-6
Replacing the Driving Belt 9-6
Assembling the Driving Belt 9-7
The Driving Pulley-Dismounting 9-7
Taking the Driving Pulley Apart 9-7
Checking the Driving Pulley 9-8
Assembling the Driving Pulley 9-9
The Overrunning Clutch Removal 9-9
Checking and Assembling 9-9
the Overrunning Clutch
Topic Page
The Clutch/Transmission Pulley 9-10
Removing the Clutch/
Transmission Pulley
Disassembling the Clutch/ 9-10
Transmission Pulley
Checking the Clutch 9-11
Transmission Pulley
Replacing the transmission pulley 9-12
and the bearing
The Clutch/Transmission 9-13
Pulley Assembly
Assembling the Clutch Housing 9-14
