NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 12: THE FRONT WHEEL, FRONT BRAKE,
FRONT BUFFER AND THE FRONT FORK
12. The Front Wheel, Front Brake,
Front Buffer and the Front Fork
6. Coat the oil seal with grease, and
then install it.
7. Attach the collar.
Assembling the front wheel.
1. Point the lug of the gear bank of
the speedometer to the notch of the
front fork leg. Then assemble the front
wheel.
2. Install the speedometer and adjust
its routing.
3. Tighten Axle Nut
Torque:
5.0-7.0kg/m 35-40ft lbs
7
COLLAR
OIL SEAL
SPEEDOMETER
CABLE
FRONT BRAKE HOSE
3
1
2
WHEEL AXLE
