1. General Information
Product Specifications and Technical Data
1-2
2
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 1: INTRODUCTION
Scooter Model Retro
Fusion
Freedom
Length 1685mm (66.5 inches)
Width 660mm (26 inches)
Height 1070mm (42 inches)
Wheel base 1195mm (47 inches)
Engine type 4-stroke OHC
Displacement 49.5cc
Fuel requirements Lead-free gasoline
Dry weight
Front 35kgs (77 lbs)
Rear 56kgs (123 lbs)
Total 91kgs (200 lbs)
Curb weight
Front 37kgs (81.5 lbs)
Rear 60kgs (132 lbs)
Total 97kgs (213.5 lbs)
Tire size
Front 3.00 x 10
Rear 3.00 x 10
Ground clearance 80mm (3.25 inches)
Stopping distance 4m from 30km/hr
16 ft from 18 mph.
Turning radius 1.65m (5.5 ft)
Engine Specs
Type 4-stroke SI
Starting Electric/kick start
Cylinders Single
Combustion chamber Hemispherical
Valve train Single OHC
Bore 39mm (13.34 inches)
Stroke 41.4mm (1.63 inches)
Displacement 49.5cc
Compression ratio 10.5:1
Compression pressure 15kg/cm
215psi
Power 2.2 HP @ 8000 RPM
Torque 4.5 ft lbs @ 6000 RPM
Intake timing 6˚ BTDC-28˚ ATDC
Exhaust timing 38˚ BBDC-6˚ BTDC
Valve lash .05mm
Idle speed 1850-1900RPM
Oil system Pressure/splash
Oil pump Internal gear
Oil filter Full-flow filter and screen
Oil capacity .8L (32 oz)
Cooling Ducted forced air
Air cleaner Foam and paper
Carburetor type CVK 50
Venturi 18mm
Throttle mechanism Butterfly type
Ignition system CDI type
13˚BTDC @ 2000 RPM
Spark plug NGK C7HSA Champion
Z9Y
Gap .5-.6mm (.022-.024 inch)
Battery 12V 4AH
Drive system
Clutch Dry multi plate
Transmission CVT
Shifting Automatic
Final Drive Double reduction
1st step 3.2:1
2nd step 3.4:1
Steer tube angle 64˚
Steering angle 45˚
Tire pressure front 1.75kg/cm (26psi)
Tire pressure rear 2.25kg/cm (35psi)
Front brake Hydraulic disc
Rear brake Mechanical drum
Suspension front Telescopic
Suspension rear Trailing arm
Shock absorber front Coil spring/hydraulic
Shock absorber rear Coil over hydraulic shock
Frame type Tubular space frame
