NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 12: THE FRONT WHEEL, FRONT BRAKE,
FRONT BUFFER AND THE FRONT FORK
12. The Front Wheel, Front Brake,
Front Buffer and the Front Fork
Topic Page
Instructions 12-2
Troubleshooting 12-3
Removing the Steering Handlebars 12-4
Assembling the Steering Handlebars
12-4
Front Wheel Removal 12-5
Dismantling of Wheel 12-6
Assembly of Wheel 12-7
Assembling the front wheel 12-8
Dismounting the Front Shock 12-9
Topic Page
Dismantling the Front Shock 12-10
Assembling Sequence 12-11
The Front Fork 12-12
Replacing the Ball Cone Race 12-12
Replacing the Upper Race 12-12
Assembling the Upper Race 12-13
Checking the Brake Lining 12-14
Dismantling the Front Brake 12-14
Assembling the Front Brake 12-14
Item
Tech Criterion
110 (4.33 in.)
4.0 (.157 in.)
202.5 (7.97 in.)
Longitudinal Hop
Transversal Wobble
0.2 (.197 in.)
2.0 (.079 in.)
2.0 (.079 in.)
111(4.36 in.)
2.0 (.079 in.)
198 (7.78 in.)
Bending of the wheel axle
ID of the front brake hub
The thickness of the brake lining
The free length of the front shock spring
Runout of the front
wheel rim
Normal Size Limit (mm)
Notes:
When detaching the front wheel, use a jack at the bottom of the frame to support it. Make sure
that the scooter won’t overturn when the front wheel is away from the ground. During operation,
be sure not to let oil get into the brake hub or onto the brake lining.
Torque
The steering lever 4.0-5.0kg/m 30ft lbs
The nut of the steering lever 8.0-12.0kg/m 50-60ft lbs
The top race of the steering lever 0.5-1.3kg/m 40-70in lbs
The nut of the front buffer 2.0-2.5kg/m 16ft lbs
The nut of the front wheel axle 4.5-5.0kg/m 30ft lbs
The bolt of the brake rock arm 0.4-0.7kg/m 30-50in lbs
