2. Body Cover and Exhaust System
2-1
28
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 2: BODY COVER AND EXHAUST SYSTEM
•Do not use excessive force when removing body
panels. Use a firm, consistent force to disengage
the tabs and remove the panels.
•Do not pry or pound on the body panels. The
mounting tabs are not designed to withstand
prying, pounding or twisting.
Parts to be removed and sequence of removal.
•Front headlight and meter cover.
•Back headlight and meter cover.
•Front fender.
•Front body cover.
•Front body panel.
•Seat and helmet box.
•Rear handhold and taillight assembly.
•Footboard cover and battery cover.
•Footboard and rear cover.
•Front frame cover.
•Covers and body side panels.
•Bottom cover.
Torque requirements
•Body mounting nuts and screws 1.2kg-m
•Exhaust pipe bolts 35kg-m
Topic Page
General Information 2-1
Body Cover Removal 2-2
Exhaust System Removal 2-4
General Information
