12. The Front Wheel, Front Brake,
Front Buffer and the Front Fork
SPEEDOMETER
CABLE
FRONT DISC
BRAKE HOSE
3
The Front Fork
Front fork removal
1. Detach the handlebar (refer to
12-3).
2. Remove the front wheel (refer to
12-4).
3. Remove the cable of the
speedometer, the rear brake cable,
the front brake hose and the front
brake caliper.
4. Remove the top race of the
steering lever and slide them out of
the steering tube.
5. Check if the ball race and the
balls on the cone race are worn or
failed. Replace as necessary.
Replacing the Ball Cone Race
1. Remove the race with a chisel
and hammer.
Attention:
Don’t damage the steering
lever and the front fork.
2. Use a suitable driver to drive in
the new cone race into place.
Replacing the Upper Race
1. Remove the upper race using a
puller or prying tool.
4
1
TOP BALL RACE
BALL CONE
RACE
To Next Page
