12. The Front Wheel, Front Brake,
12-7
130
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 12: THE FRONT WHEEL, FRONT BRAKE,
FRONT BUFFER AND THE FRONT FORK
Front Buffer and the Front Fork
2. Detach the rim bearing
and the spacer.
Assembly
1. Fill the bearing with
grease
2. Drive the left bearing first.
3. Install the spacer, then
drive in the right bearing.
Attention:
Keep the oil (dust)
seal side of the
bearing outwards,
then drive it evenly.
BEARING
of Wheel
