NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 13: THE REAR WHEEL,
THE REAR BRAKE & REAR BUFFER
Important Points
During operation, it’s not allowable to have oil adhere to the inner surface of the brake hub and the
surface of the lining. Use brake solvent to remove oil.
Topic Page
Important points 13-2
Troubleshooting 13-2
Detaching the Rear Wheel 13-3
Checking the Rear Wheel 13-3
Assembling The Rear Wheel 13-3
Topic Page
Checking the Rear Brake 13-4
Dismantling the Rear Brake 13-4
Assembling the Rear Brake 13-4
Dismounting the Rear Shock 13-5
Assembling the Rear Shock 13-6
Check Position Item
Tech Criterion
Longitudinal Hop
Transversal Wobble
2.0 (.079 in.)
2.0 (.079 in.)
111 (4.36 in.)
2.0 (.079 in.)
198 (7.78 in.)
Rear Wheel Runout
Free length of the rear shock spring
ID of the rear brake hub
Thickness of the rear brake lining
Normal Size Limit (mm)
Torque
The nut of the rear wheel axle 10.0kg•m 75ft lbs
The top of the rear buffer 4.5kg•m 30ft lbs
The bottom bolt of the rear buffer 3.0kg•m 20ft lbs
The connection nut of the silencer 1.2kg•m 10ft lbs
The fix bolt of the silencer 3.5kg•m 25ft lbs
Diagnosis
The rear wheel wobbles
•Deformation of the rear rim
•Bad tire mounting or bent
The rear shock is too weak
•Spring bent or broken
Misadjusted brake
•Wear of the brake lining
•Wear of the brake lining cam
•Brake cam worn
•Brake hub worn
110 (4.33 in.)
4.0 (.157 in.)
202.5 (7.97 in.)
