3. Scheduled Maintenance
3-11
43
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 3: BODY COVER AND EXHAUST SYSTEM
Nut and Bolt Tightness
1. Check all nuts and bolts for proper tightness.
2. Adjust torque as necessary.
Collar Rim Tire
1. Check tire pressure.
Measure tire pressure when tire is cold.
Air Pressure
Tire Standards
•Front tire: 3.00 x 10
•Rear tire: 3.00 x 10
1. Check if front wheel axle has slack.
2. Check if rear wheel axle nut has slack.
3. Tighten when necessary to stipulated torque if
there is slack.
Torque:
•Front wheel axle nut 4.0-5.0 kg-m 28-32 ft lbs
•Rear wheel axle nut 8.0-10.0 kg-m 55-65 ft lbs
Front Tire 1.75kg/cm 17psi
Rear Tire 2.00kg/cm 23psi
1
CHECK TIRE
PRESSURE
