Panterra Fusion - Assembling the Rear Shock

13. The Rear Wheel, the Rear Brake & Rear Shock
13-6
145
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 13: THE REAR WHEEL,
THE REAR BRAKE & REAR BUFFER
Assembling the Rear Shock
1. Attach the rear shock.
2. Install the top bolt of the shock.
3. Install the bottom bolt of the shock.
4. Tighten the nuts and the bolts.
Torque
Top bolt: 4.5kg•m 30ft lbs
Bottom bolt: 3.0kg•m 20ft lbs
5. Assemble the lid of the body.
3
4
BOTTOM BOLT
TOP BOLT
CHASIS
