3
4
LOWER CLAMP BOLT
UPPER CLAMP BOLT
Dismounting the Front Shock
1. Remove the front wheel (refer
to 12-4).
2. Remove the lower front cover
(refer to 2-1).
3. Remove the upper clamp bolt.
4. Loosen the lower clamp bolt to
take out the front shock.
12. The Front Wheel, Front Brake,
12-9
132
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 12: THE FRONT WHEEL, FRONT BRAKE,
FRONT BUFFER AND THE FRONT FORK
Front Buffer and the Front Fork
