11. The Crankcase and the Crankshaft
11-4
119
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 11: THE CRANKCASE AND THE CRANKSHAFT
OIL SEAL
8
1
CRANKSHAFT
7. Scrape the gasket away from
the joint surfaces.
Attention: be sure not to
scratch the joint surfaces.
8. Remove the oil seal from the
left crankcase.
9. Remove the oil seal from the
right crankcase.
The Crankshaft
1. Measure the left and right
clearance between both sides of
the big end of the connecting rod.
Maximum service allowance:
Replace when it goes beyond
0.55mm (.02 in.).
