14. The Battery and the Charging System
14-10
155
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 14: THE BATTERY AND THE CHARGING SYSTEM
3. Remove the four bolts and remove
the cooling fan.
4. Use a universal solid wrench to
secure the flywheel. Detach the fix nuts
of the flywheel.
5. Use a spanner wrench hold flywheel
while removing the retaining nut.
6. Use a flywheel puller to remove the
flywheel.
7. Remove and save the key.
8. Detach the connecting wire of the
magneto.
3b
4 5
COOLING
FAN
3a
FLY WHEEL
UNIVERSAL
WRENCH
SPANNER WRENCH
