5. Fuel System
5-5
56
NIKOTA USA: PANTERRA SCOOTER SERVICE MANUAL
CHAPTER 5: FUEL SYSTEM
5. Check pin and seat for
wear.
6. Replace if necessary.
7. Place auto choke in
mounting location and press
down firmly.
8. Put lock ring in position and
fasten screw
AUTO CHOKE
MOUTING LOCATION
8
5
7
FIX PLATE
LOCK RING
SCREW
PIN
