Parker P Series

Parker Hannifin
P Series User Guide 211
Set Value Descriptions
0 Uses built-in regeneration brake
1
Uses external regeneration brake.
In this case, make sure to set the regeneration brake value (0x200B) and
power (0x200C) to the right values. For wiring of external regeneration
brake, see “ 3.6.2 External Resistor Setting “.
0x200A Regeneration brake Resistor Derating Factor ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT 0 to 200 100 % RW No Servo Off Yes
Set the derating factor for regeneration brake overload check. Setting the value to
100[%] or below will set off the regeneration overload alarm (AL-23) faster. Setting the
value to 100[%] above will set off the alarm slowly. Please adjust the set value in
accordance with the heat protection condition of the regeneration brake. When setting
the value to 100% or above, please take the heat protection condition into
consideration.
.
0x200B Regeneration brake Resistor Value ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT 0 to 1000 0 ohm RW No Servo Off Yes
When using an external regeneration brake (0x2009=1), sets the value of the
external regeneration brake by ohm. When using the built-in regeneration brake
(0x2009= 0), the set value does not apply.
0x200C Regeneration brake Resistor Power ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT 0 to 30000 0 watt RW No Servo Off Yes
When using an external regeneration brake (0x2009=1), sets the power of the
external regeneration brake by watt. When using the built-in regeneration brake
(0x2009= 0), the set value does not apply.
0x200D Peak Power of Regeneration brake Resistor ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
1 to 50000
100
watt
RW
No
Servo Off
Yes
