Parker P Series

Parker Hannifin
P Series User Guide 226
bit
Setting Details
0
BRAKE
1
ALARM
2
READY
3
ZSPD
4
INPOS1
5
TLMT
6
VLMT
7
INSPD
8
WARN
9
TGON
10
INPOS2
15-11
Reserved
0x2122 Drive Status Output 2 ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 0xFFFF
0
-
RO
Yes
-
No
Other than outputting the drive’s output signal status by allocating it to the I/O connector
output signal, you can check the bit corresponding to the output value.
bit
Setting Details
0
ORG
1
EOS
2
IOUT0
3
IOUT1
4
IOUT2
5
IOUT3
6
IOUT4
7
IOUT5
15~8
Reserved
