Parker P Series

Parker Hannifin
P Series User Guide 225
9
Reserved
10
EMG
11
A_RST
12
SV_ON
13
SPD1 / LVSF1
14
SPD2 / LVSF2
15
SPD3
0x2120 Drive Control Input 2 ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT 0 to 0xFFFF 0 - RW Yes
At all
times
No
This is the same function as [0x211F], with different descriptions. Please see the table
below for input descriptions.
bit
Setting Details
0
START
1
PAUSE
2
REGT
3
HSTART
4
ISEL0
5
ISEL1
6
ISEL2
7
ISEL3
8
ISEL4
9
ISEL5
10
ABSRQ
11
JSTART
12
JDIR
13
PCLEAR
14
AOVR
15
Reserved
0x2121 Drive Status Output 1 ALL
Variabl
e
Format
Setting Range
Default
Value
Unit
Acces
sibility
PDO
Allocati
on
Change
Property
Stor
e
UINT
0 to 0xFFFF
0
-
RO
Yes
-
No
Other than outputting the drive’s output signal status by allocating it to the I/O connector
output signal, you can check the bit corresponding to the output value.
