EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
INTELLIFLO VS SPEEDS SETTING:
Down button: ChooseSpeeds.
Right button: AccesstheIntelliFloVSspeed(RPM)settings forPump#1.
Up/Down button: Selectthecircuit number 1 of 4(1/4).
Right button: MovetoRPMtochangethepumpspeed.
Up/Down buttons: Setspeedofthepumpfrom400to3450RPMinincrementsof
10RPM.Thedefaultspeedforeachcircuitcorrespondtothefourspeedbuttonson
theIntelliFloVScontrolpanelis:Speed 1 button 750 RPM, Speed 2 button 1500
RPM, Speed 3 button 2350 RPM, and Speed 4 button 3110 RPM.
INTELLIFLO VSF+SVRS FLOW RATE SETTING:
Down button: ChooseFlow/Speeds.
Right button: AccesstheIntelliFloVSF+SVRSspeed(RPM/GPM)settings forPump
#1.
Up/Down button: Selectthecircuit number 1 of 4(1/4).
Right button: MovetoGPMtochangethepumpowrate.
Up/Down button: SelectRPM or GPM.PressUp/Down buttontotogglebetween
RPMandGPMandpressuresetting(PSI).
Right button (GPM): MovetoGPMpumpowrate.
Up/Down button: Setspeedofthepumpfrom15to130GPM.Thedefaultow
rateis30GPM.Thepresetspeedforeachbuttonis:Speed 1 button 1100 RPM
(30 GPM), Speed 2 button 1500 RPM, Speed 3 button 2350 RPM, and Speed 4
button 3110 RPM.
Right button (GPM/PSI):MovetoPSI(poundspersquareinch)pressuresetting.
Up/Down button: Selectthepumppressuresettingfrom1to30PSI. See above for
equivalent default RPM/GPM (speed/flow rate).
VS and VSF+SVRS CIRCUIT SETTING:
Right button: Movetothecircuitnames.
Up/Down buttons: Assign the pump circuit: NONE, SPA, POOL, AUX 1-3,
FEATURE 1-2, HEATER, POOL HEATER, SPA HEATER, FREEZE, POOL/SPA, and
SOLAR/HEAT.
Right button: PresstheUp arrow buttonandgotothenextcircuitpagesettings
(2/4)andrepeattheprevioussteps.
Whennishedsettingupthecircuits,presstheMenubuttontosavethesettingsand
toreturntotheSettingsmenuoptions.Pressthebuttontwotimestoreturntothe
mainscreen.
INTELLIFLO VS STATUS SETTING:
Down button: ChooseSTATUS.
Right button: ViewthecurrentIntelliFloVSpumpstatus.
Menu: PressMENUtoexit.
IntelliFlo VS and VSF+SVRS Settings (Continued)


Pump #1 Type
Type: VS
Pump #1 1/4
RPM: 1200
Circuit:
[ POOL ]


Pump #1 1/4
GPM:30 PSI: 15
Circuit:
[ NONE ]


Pump Type
Flow/Speeds
Status



Pump #1 Type
Type: VSF+SVRS


Pump #1 1/4
GPM:30 PSI: 15
Circuit:
[ AUX 1 ]


GPM: 30
1200 RPM 12 W
Watts: 10
Status: GOOD


