EASYTOUCH
®
PL4/PSL4 Control Systems User’s Guide
  37
INTELLIFLO VS STATUS SETTING:
Down button: ChooseSTATUS.
Right button: ViewthecurrentVSstatus.
Menu: PressMENUtoexit.
IntelliFlo VF 3050 pump Settings
Assigning an IntelliFlo VF 3050 Pump Address
Beforeassigningapumpaddress,rstsettheaddresson the pump itself.Ifthereisonlyonepump,itis
alwaysseenaspump#1bytheEasyTouchPL4/PSL4ControlSystem.Inthiscaseyoudonotneedtosetthe
pumpaddress.Theaddressshouldbesetto#1.TheaddresssetatthepumpmustmatchtheIntelliFlopump
numberselectedinthesystemIntelliFloPUMP # > PUMP TYPE menus.
Note: IntelliFlo VF 3050 pumps cannot be connected in series with other pumps.
Check valves must be used when a pump is used in parallel with other pumps.
ToassignanIntelliFloVF3050pumpaddress:
1. PresstheStart/Stopbuttontostopthepump.BesurethatthegreenpowerLEDisonandthepump
isstopped.
2. PresstheMenu button.
3. PresstheUp and Downarrowbuttonstoscrollthroughthemenuitems.PresstheSelectbuttonto
accessthe“PoolData”menu.
4. PresstheSelect buttontoaccessthe“PumpAddress”setting.
5. PresstheSelect buttontochangethecurrentpumpaddress.
6. Toenterthenewaddressnumber,presstheLeftandRightarrowstoselectwhichdigittomodify,
thenusetheUpandDownarrowstochangetheselecteddigit.
7. Whenyouaredoneassigningthepumpaddressnumber,presstheEnterbuttontosavethechanges.
Tocancelanychanges,presstheEscapebuttontoexiteditmodewithoutsaving.
NOTE: INTELLIFLO “FREEZE” PROTECTION - If the IntelliFlo pump is on due to a freeze condition (not switch on from
a relay circuit state), and if a freeze speed/flow is set, this setting takes priority even if the previous setting is lower than
the default circuit speed. If no “freeze” protection is set, the pump will be forced on at the default circuit speed/flow. Any
programmed or manual operation that actually switches on a circuit, will cause the pump to run at that speed if it is higher.
NOTE: INTELLIFLO IN “SERVICE MODE” - The IntelliFlo pump will STOP when the control system is in ‘Service” mode.
NOTE: INTELLIFLO VF PUMPS - If the IntelliFlo VF pump is just starting (requiring a prime) and SOLAR is available, solar
will be delayed for five (5) minutes to allow the pump to prime. This only applies for IntelliFlo pump(s) assigned as to a “pool”
pump.
INTELLIFLO VS PRIMING SETTING:
Down button: ChooseSPEEDS.
Right button: Accesstheprimingsettings.
Up/Down button: Adjusttheprimingtimefrom0to5minutes.
Right button: MovetoSPEED (RPM)tochangethepumpspeed.
Up/Down buttons: Setspeedofthepumpfrom400to3450RPMinincrementsof
10RPM.Thedefaultspeedforeachcircuitcorrespondtothefourspeedbuttonson
theIntelliFloVScontrolpanelis:Speed 1 button 750 RPM, Speed 2 button 1500
RPM, Speed 3 button 2350 RPM, and Speed 4 button 3110 RPM.
IntelliFlo VS and VSF+SVRS Settings (Continued)


Pump Priming
Time: 0
Speed: 1000
Pump Status
RPM: 1200
Watts: 10
Status: GOOD


Pump Type
Speeds
Priming
Status



Pump Type
Speeds
Priming
Status



