E-Drill General Fault
Trouble
Probable Cause
Remedy
Cutting not to depth. Water
leaking around tip.
Hand-tool not firmly and
consistently held in contact
with fastener and airframe
surface throughout cut.
Press hand-tool firmly over
fastener and maintaining
pressure until cut is complete.
Cycle time excessively long.
Cutting too deep.
Hand-tool is not held stable
during cut.
Hold hand-tool in a fixed
position during cutting.
Electrode is not tight.
Tighten electrode.
Cut slower than expected.
Electrode is not tight.
Check electrode tightness with
electrode torque wrench.
Ground Pin protrusion not
sufficient, restricting water flow
and/or causing bad ground
connection.
Adjust Ground Pin protrusion
with Ground Pin Setting Tool.
Air in system.
Bleed DI system.
Leaks in water system.
Check visually for leaks in
water system or for crimped
hoses. If you have access to a
pressure gauge then check
water pressure (see section
3.8, page 48.)
Wrong fastener selected.
Check fastener settings.
Wrong electrode type.
Check electrode material
application.
Operator error.
User lifted or moved E-Drill
during cut sequence.
