12
Workshop Manual, TSD3450E, Issue 1 119
2800
To renew Operation 12-8
1 Remove the fan, Operation 12-5.
2 Loosen the belt tensioner and remove the old belts. Ensure that the grooves of the pulley are free from
grease and dirt and fit a new set of belts.
3 Fit the fan and tighten the bolts securely. Adjust the fan belts to the correct tension, as given in Operation
12-7.
