During meter usage
NOTE
A small dot maybe spotted at the LCD.
This condition is normal and does not
indicates a problem.
2
1
0
3
x1000r/min
6
7
8
5
4
The tachometer indicates the engine
revolutions per minute.
The red zone indicates engine over-revving.
Red zone indicator varies according to type
of meter.
CAUTION
Do not over-rev the engine to prevent
engine damage.
Tachometer
0
20
40
60
80
100
120
140
160
180
200
km/h
ODO/TRIP DISP
Speedometer
The pointer indicates vehicle speed.
